Wires: 8 circuits (4 twisted pairs)
Standard wire colours: Blue/blue-white orange/orange-white green/green-white and brown/brown-white
Solid wire: AWG 23/1
Materials: HDPE insulator PE jacket
Frequency: Maximum 250MHz
Operating temperature: -20°C to 75°C
DC-Loop resistance: 0.0658
Propagation speed: 0.64
Propagation delay: 4.80–5.30 ns/m
Delay skew: Ë‚ 100 MHz Ë‚ 0.20 ns/m
Capacitance: f.f.s
Return loss (Min. at 250MHz): 15.6 dB
Attenuation (Min. at 250MHz): 39.4 dB
Standards: EIA/TIA 568 B.2 EN 50173-1 ISO/IEC 11801
Reviews
Strong and robust cables for external use.
Hi Paul, thank you for your review!
Cable as described, and arrived quickly, cheaper than some other outlets and weatherproof.
