Hikmicro Lynx Pro 19mm Smart Thermal Surveillance Monocular

Hikmicro Lynx Pro 19mm Smart Thermal Surveillance Monocular

Product Code: HIKMICRO-LH19(19mm)
£1,099.99
Add optional extras
  • 35mK NETD Rating - one of the most sensitive sensors available on the market, detecting even the smallest temperature differences!
  • Objective Focus Ring - precisely adjust the image to optimise your view over a wide range of distances.
  • 384x288px 12µm sensor - this change in pixel pitch boosts your magnification up to 1.8x allowing a detection distance of 897m (Human size target).
  • 1280 x 960px LCOS Screen - featuring the same large screen from the 35mm models, producing a clear and easy-to-use view of your surroundings.
  • 4 Colour Profiles
  • 8x Digital Magnification
  • Hot Track - activate Hot Tracking and your Lynx Pro will highlight the hottest spot detected in the current frame with a green crosshair.
  • T-Vision App compatibility - Connect, Stream and Record to your Smart Phone.

The HIK Micro Lynx Pro 19mm 35mK Smart Thermal Monocular stands as a revolutionary addition to the HIK Micro range, presenting a host of premium features in a more cost-effective device, well-suited for detailed surveillance applications.

The key characteristic of this model is its compact design, making it a pocket-sized solution for surveillance professionals. This is coupled with the added feature of a focus ring around the objective lens, which lets you adjust the image with precision to optimize your view across various distances, a critical factor when observing human targets for surveillance.

A significant technological upgrade in the Lynx Pro is the incorporation of a 384x288px 12µm sensor. This advancement in pixel pitch enhances the magnification up to 1.8x, supporting a detection distance of 897m for human-sized targets. This enhancement not only improves the device's performance but also contributes to the cost-effectiveness of the unit.

The Lynx Pro provides a large and clear view of your surroundings, enhancing user experience and making it an effective tool for monitoring people across various distances and in different lighting conditions.

Moreover, the Lynx Pro is rich with typical HIK Micro features. These include four color profiles to cater to diverse surveillance needs and digital magnification up to 8x for detailed observation. Further enhancing its functionality, the Lynx Pro is compatible with the T-Vision App, allowing you to connect, stream, and record directly to your smartphone, thus facilitating efficient data management and sharing during surveillance operations.

In summary, the HIK Micro Lynx Pro 19mm 35mK Smart Thermal Monocular is an advanced yet affordable solution for individuals in the surveillance sector, offering an array of features designed to facilitate effective monitoring of human targets across various distances.

  • MAIN
  • Sensor
  • 384×288px @ 12µm
  • Objective Lens (Focal Length)
  • 19 mm
  • Detection Range (Human 1.8 x 0.5m)
  • 897 m
  • SENSOR
  • Type
  • VOx Uncooled Focal Plane Arrays
  • Resolution, pixels
  • 384 × 288 px
  • Pixel pitch µm
  • 12µm
  • Frame rate, Hz
  • 50 Hz
  • NETD
  • <35mK
  • THERMAL OPTICS
  • Objective lens
  • F1.0
  • Magnification (Optical)
  • 1.86x
  • Magnification (Digital)
  • 1x, 2x, 4x, 8x
  • Field of view
  • 13.8° × 10.4° (H × V)
  • DISPLAY
  • Type
  • 10 mm LCOS
  • Resolution, Pixels
  • 1280 x 960
  • Colour Palettes
  • Black Hot, White Hot, Red Hot, Fusion
  • Video Recorder
  • Build in memory, Gb
  • 8 Gb
  • Additional features
  • Hot Tracking
  • YES
  • WiFI hot spot
  • YES
  • HIKMICRO Connect App support
  • YES
  • Environmental
  • Degree of protection, IP code
  • IP67
  • Dust protection
  • Protected against dust ingress
  • Water protection
  • Protected against temporary submersion in water
  • Operating temperature range
  • -20 °C to 55 °C
  • WEIGHT & SIZE
  • Dimensions, mm
  • 171 mm × 61 mm × 57 mm
  • Weight, kg
  • 0.31 kg
  • POWER SUPPLY
  • Operating time on battery (WiFi & Hot tracking disabled)
  • 7.5 hours continuous running
  • Charging interface
  • USB-C
  • Battery capacity after 1000 cycles
  • 80%
  • Warranty Period
  • Main Unit
  • 3 Years
  • Battery
  • 2 Years
  • 35mK NETD Rating - one of the most sensitive sensors available on the market, detecting even the smallest temperature differences!
  • Objective Focus Ring - precisely adjust the image to optimise your view over a wide range of distances.
  • 384x288px 12µm sensor - this change in pixel pitch boosts your magnification up to 1.8x allowing a detection distance of 897m (Human size target).
  • 1280 x 960px LCOS Screen - featuring the same large screen from the 35mm models, producing a clear and easy-to-use view of your surroundings.
  • Hot Track - activate Hot Tracking and your Lynx Pro will highlight the hottest spot detected in the current frame with a green crosshair.
  • 4 Colour Profiles
  • 8x Digital Magnification
  • T-Vision App compatibility - Connect, Stream and Record to your Smart Phone.

HIK Thermal Monocular User Manual: DOWNLOAD

Download the HIK App here:

Apple: https://apps.apple.com/us/app/t-vision/id1478705944

Android: https://www.app-st.net/ZdMM

T-Vision App Tutorial
